Pinnacle T5

The CNC milling machine Pinnacle T5 machines world class dovetails. The drawer sides, fronts, and backs are dovetailed from the same carbide tipped tooling assuring a tight dovetail fit. The T5 is an automatic NC controlled dovetail machine designed for ease of use. Operators can choose between desired joints according to demands. The NC control allows the operator to easily change the length, size, and type of each piece and save the files for future use. Machine operations are carried out through a touch screen controller located conveniently for the operator. The Italian servo router head moves on precision linear guide ways for maximum machining precision.

Categories: , . Tags: , , , .
  • Main motor 3HP 220V 3 Phase
  • Independent working fields (Left & Right) when one area is working the operator can change the parts in the other working area
  • Cutter Speed 24000 RPM
  • Transmission motors 2x1HP
  • Work piece thickness range 3/8” to 1”
  • Net weight 1465lbs
  • Machine Size (LxWxH) 71”x26”x51”
  • Weight 1450lbs

Complete with:

  • 3 Dovetail cutters
  • Tools & manual kit
  • CSA Electrical components
